Description
HCPL-3120 / A3120 is an optically-isolated gate driver designed to drive power IGBTs and MOSFETs. It combines an input GaAsP LED, an internal high-current output stage, galvanic isolation between control and power sides, suited for inverter and motor drive applications.
Key Electrical Features
-
Minimum peak output current: ~2.0 A (up to ~2.5 A peak)
-
Operating supply voltage (VCC): ~15 V to 30 V
-
Maximum low-level output voltage (VOL): approx. 0.5 V
-
Under-Voltage Lock-Out (UVLO) with hysteresis
-
Common Mode Rejection (CMR): ~15–25 kV/µs
-
Switching speed: ~500 ns max
-
Operating temperature: –40 °C to +100 °C
-
Isolation voltage: typically ~3750 Vrms
-
Package: Through-hole DIP-8 package
