Description
Specifications:
Charging Voltage: max: 10V, recommend: 5V
Charging Current: max: 1A
Lithium Battery Voltage: 3.3-4.2V
Boost Power Supply: 5V(max: 1A)
LED Color: Red for Charging, Green for Fully Charged
Charging Voltage: max: 10V, recommend: 5V
Charging Current: max: 1A
Lithium Battery Voltage: 3.3-4.2V
Boost Power Supply: 5V(max: 1A)
LED Color: Red for Charging, Green for Fully Charged
Ports:
XH2-2.54MM – Connect to lithium Battery (normal 3.3-4.2V)
Micro USB – Charging port (normal 5V)
J1 – setting max charging current, 0.5A or 1A.
